Benefits for you:
| Details | ||||
| Place of Origin: | Zhejiang, China | Protection Level: | IP65 | |
| Model Number: | MD-S101A | External Size: | 323.5Wx550Hx131D mm | |
| Type: | Metering Box | Rated Insulation Voltage UI: | 800V | |
| Installation Network: | LV: AC220V, AC380V | Main busbar rated current In: | 10A-250A | |
| Installation Type: | Wall Mounted/Pole Mounted | Insulation Resistance: | ≥20ΜΩ | |
| Installation Location: | Indoor/Outdoor | Material: | PC and ABS Plastic | |
| Frequency: | 50Hz or 60Hz | Life Expectancy: | ≥30 years |
Technical parameters
| Technical Specification | |
| Installation Network: | LV: AC220V,AC380V |
| Installation type: | wall mounted/polc mounted |
| Installation location: | Indoor/outdoor |
| Frequency: | 50Hz or 60Hz |
| Main busbar rated short time withstand current low: | 30kA |
| Insulation resistance: | ≥20MΩ |
| Rated insulation voltage UI: | 800V |
| Material: | PC+ABS |
| Protection Class: | IP65 |
| Life Expectancy: | ≥30 years |
| Main busbar rated current In: | 10A~250A |
| Dimension(WxHxD): | 323.5x550x131mm |
