Pv Array Dc Combiner Box Solar String Boxes

  • Features
  • Accessories

Benefits for you:

Features:


System maximum de voltage550/1000
Maximum input strings6
Maximum input current for each string16A
Maximum output switch current20A/32A
Number of inverter
Number of output strings
Nominal discharge current20KA
Maximum discharge current40KA
Voltage protection level2.8KV/3.8KV
Maximum continuous operating voltage Uc630V/1050V
MC4 Connectors/dc fuse/dc surge protectorStandard
Box materialPC/ABS
Installation methodWall mounting type
Operating Temperature-25°C-+55°C
Permissible relative humidity0-95%, no condensation



Technical parameters
